Model |
YZL-40YS/D |
YZL-50YS/D |
YZL-60Y S/D |
YZL-70YS/D |
YZL-80YS/D |
YZL-100YS/D |
YZL-110YS/D |
|
電源/Power supply |
V/PH/HZ |
380/3/50 |
|
制 冷 量
Cooling capacity |
KW |
53.3 |
72.7 |
95.3 |
103.8 |
126.5 |
138.9 |
163.6 |
|
Kcal/hr |
45838 |
62522 |
81958 |
89268 |
108790 |
119454 |
140696 |
|
壓縮機
compressor |
類型/Type |
半封閉螺桿式Semi-sealed screw type |
|
容量控制%Capacity control |
0-25%-50%-75%-100% |
|
數量/quantity |
1 |
|
功 率
Input power |
21 |
27.7 |
34.7 |
38 |
46.3 |
50.4 |
56.8 |
|
啟動方式
logon mode |
Y-△/△-△分繞組 Y-△/Shut Winding |
|
運轉電流（A）
/running ampere |
35.9 |
47.2 |
59.2 |
64.9 |
79.1 |
86.1 |
97 |
|
啟動電流（A）
Staring ampere |
90 |
118 |
148 |
163 |
198 |
216 |
243 |
|
冷凍油 freeze oil |
類型Type |
HBR-B03/B320SH |
|
容量/Volume |
9 |
10 |
10 |
15 |
15 |
15 |
15 |
|
冷媒refrigerant |
類型/Type |
R22 |
|
充注量/Volume |
21kg |
31kg |
38kg |
48kg |
56kg |
69kg |
81kg |
|
控制方式/ Control |
熱力膨脹閥 Expansion valve |
|
蒸發器Evaporator |
類型/Type |
防腐殼管式高效換熱器 igh efficiency heat exchanger |
|
冷凍水流量m3/h
Chilled water flow |
9.17 |
12.5 |
16.4 |
17.9 |
21.8 |
23.9 |
28.1 |
|
管徑/Pipe Size |
DN65 |
DN65 |
DN80 |
DN80 |
DN100 |
DN100 |
DN100 |
|
壓降/Water lost |
≤0.07 |
|
冷凝器Condenser |
類型/type |
殼管式高效換熱器 High efficiency heat exchanger |
|
冷卻水流量/m3/h
cooling water flow |
12.8 |
17.3 |
22.4 |
24.4 |
29.7 |
32.6 |
37.9 |
|
管徑/Pipe Size |
DN65 |
DN65 |
DN80 |
DN80 |
DN100 |
DN100 |
DN100 |
|
壓降/Water lost |
≤0.07 |
|
安全保護Protection |
高、低壓保護、過載保護、電流保護、逆相保護、油壓保護、排氣過熱保護、壓縮機高溫保護。High and low pressure protection、overload protection、current protection、reversed phase protection、Oil pressure protection、exhaust over temperature protection 、compressor temperature protectio, n. |
|
外形保護dimension |
L |
mm |
2050 |
2150 |
2450 |
2450 |
2550 |
2850 |
2950 |
|
W |
mm |
980 |
980 |
980 |
980 |
1050 |
1150 |
1150 |
|
H |
mm |
1380 |
1420 |
1500 |
1520 |
1620 |
1660 |
1760 |
|
機組重量Net weight |
kg |
920 |
1010 |
1080 |
1300 |
1420 |
1530 |
1670 |
